Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: transon
  • Model Number: TSA1224
  • Voltage: AC220V±10% / 50~60Hz
  • Power(W): 1.5kw
  • Weight: 800kgs
  • Certification: CE
  • Warranty: Warranty period for Cnc router machine:one year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • X,Yworksize: 1250x2450
  • Z axis worksize: 160 mm
  • control system: Mach3 - USB port (DSP optional)
  • spindle power: 1.5kw water cooling (0-24000rpm)
  • cooling way: water cooling
  • command: HPGL, G code
  • Structure: Iron casting bobby . Gantry moving type
  • type: acrylic cnc machine
  • x,y use: 2510 ballscrew and SBR25 rails
  • Tool bits shank: 3.175-6mm

Packaging & Delivery

Packaging Details Standard export plywood package
Delivery Time within 7-10 days after receive the deposite

Furniture making machine  wooden door   engraving machine  TSA1224



Product Description



Features

1. X Y use SBR25 supported  rails. and 25mm diameter , C7 precision ballscrew made from Taiwan.

strong rails   and high precision ballscrew make these model machine working very stable and more durable.

( square rails option)

2. Aluminium casting whole body wont transform for long use.

3. Iron casting table body insure machine movement of working more stable and low noisy.

4. mach3 controller with usb port. you can use your laptop to control machine ( DSP controler option)

Applicable Industries

 Billboard industry, cutting plate production, LED / neon light trough, literally shaped hole cut,
light box molding, and so on.

Applying material:

PVC, Rubber, ABS plate, Acrylic, double-color sheet, wood, MDF, Organic glass,
copper, ACP, plastic, metal and so on.

Specification:



Model

TSA1212

TSA1218

TSA1224

X Y Z travel

1250x1250x160mm

1250x1850x160mm

1250x2450x160mm

Feeding height

170 mm

Structure

Iron casting bobby .   Gantry moving type

Transmit

High precision ball screw

Rails slide

X Y Z ----- Round rail (square rail option )

Drive type

Stepper  (servo optional )

Spindle power

1.5kw water cooled (0-24000rpm)

Working Speed

0-4000mm/min

Control system

Mach3 -usb port    (DSP optional)

Command code

HPGL, G code

Working precision

0.05mm

Repeatability

0.01 mm

Power

AC220V±10% / 50~60Hz

Compatible Software

Type3/Artcam/UG/Pro-E/Mastercam/Ucancam V8 etc

Tool bits shank

3.175-6m



Machine picture













sample









 Samples

 Wood



 Stone





Packaging & Shipping





Package



More model







Our Services



1.Warranty period for Cnc router machine:one year

2.Warranty period for spindle:half year

3.Free replacement if there is a failure in warranty period

4.Professional technical person provide service online all the time by skype, email and son on.

Trade assurance





Alibaba assessed 5 year gold supplier
and Trade AssuranceUSD$25,000









♥ If you want to know more information about our products welcome to contact us at any time.



And welcome to our company! We display more new design in our showroom .

We are sincerely looking forward to receiving your inquiry. Thank you very much.
